FMUSER DTV-4696 2/4/8 CI Slots and 2/4/8 DVB-C/T/ISDB-T/DVB-S/S2/S2X/ATSC or 1/2 ASI and 16 IP(UDP/RTP) in 1 MPTS and 16 SPTS or 1/2 ASI out Satellite
1.2/4/8 Tuner (DVB-C/T/ISDB-T switchable or DVB-S/S2/S2X or ATSC optional) inputs for each demodulation module
2.1 ASI & 16 IP (UDP/RTP) inputs for re-mux, IP (1 MPTS & 16 SPTS) over UDP and RTP output; ASI out for MPTS
3.Support maximum 256 PID mapping
4.Support BISS descrambling
5.Remote control and Firmware, web NMS management
Details:
FMUSER DTV-4696 2/4/8 CI Slots and 2/4/8 DVB-C/T/ISDB-T/DVB-S/S2/S2X/ATSC or 1/2 ASI and 16 IP(UDP/RTP) in 1 MPTS and 16 SPTS or 1/2 ASI out Satellite Receiver
Overview:
The FMUSER DTV-4696 Multi-Channel CI Slots Receiver is a state-of-the-art device that combines demodulation and de-scrambling functions into a single unit. This innovative device is designed to convert RF signals into TS output after re-muxing. It is a 1-U case that supports up to 2 demodulation modules; with each module accommodating 2/4 CAMs/CIs to decrypt programs from encrypted RF; ASI; and IP inputs. The device also features BISS function to descramble programs from any input. Also suitable Cable digital TV adjacent frequency front-end system; hotel IPTV network TV system and hotel satellite digital TV system.
Features:
Input and Output Ports: FMUSER DTV-4696 is equipped with 2 or 4 tuner inputs (DVB-C/T/T2/ISDB-T switchable or DVB-S/S2/S2X or ATSC optional) for each demodulation module. Each module also has 1 ASI in and 16 IP inputs for re-muxing. This feature-rich device outputs 1 MPTS and 16 SPTS with 1 ASI out port and 1 data port; transmitting IP (1 MPTS & 16 SPTS) over UDP and RTP protocols. The device also has a maximum of 256 PID mapping; offering advanced customization options.1 ASI & 16 IP (UDP/RTP) inputs for re-mux
Advanced Features: The FMUSER DTV-4696 supports remote control and firmware; web NMS management; making it easy to manage and configure the device remotely. The device can also be updated via web; ensuring that it remains up-to-date with the latest features and functionality.Cost-Effective Solution: The FMUSER DTV-4696 Multi-Channel CI Receiver offers outstanding quality at a breakthrough price point. The device is designed to be cost-effective; making it an excellent choice for customers who want high-quality output signals without breaking the bank.
FMUSER DTV-4696 Multi-Channel CI Receiver supports a maximum of 256 PID mapping; which provides advanced customization options for users. This feature allows users to map specific PID values to different programs; ensuring that the output signals are tailored to their specific needs. With a maximum of 256 PID mapping; users can create customized output signals that are optimized for their broadcasting applications. This feature-rich device offers outstanding quality at a breakthrough price point; making it an excellent choice for customers who want high-quality output signals without breaking the bank.
Principle Chart (each demodulation module):
Technical Specifications:
Input | 2 or 4* tuner inputs (DVB-C/T/T2/ISDB-T switchable or DVB-S/S2/S2X or ATSC optional); F type | ||||||
Tuner Section | Multi-mode tuners switchable | DVB-C | Input Frequency | 60 ~890 MHz | |||
Standard | J.83A; J.83C | J.83B | |||||
Constellation | 16/32/64/128/256 QAM | 64/256 QAM | |||||
DVB-T/T2 | Input Frequency | 60 ~890 MHz | |||||
Bandwidth | 6/7/8 M | ||||||
ISDB-T | Input Frequency | 60 ~890 MHz | |||||
Satellite | DVB-S | Input Frequency | 950~2150MHz | ||||
Symbol rate | 0.5~45Msps | ||||||
Signal Strength | - 65- -25dBm | ||||||
FEC | 1/2; 2/3; 3/4; 5/6; 7/8 | ||||||
Constellation | QPSK | ||||||
Max input bitrate | ≤170 Mbps | ||||||
DVB-S2 | Input Frequency | 950~2150MHz | |||||
Symbol rate | QPSK/8PSK /16APSK :0.5~45 Msps | ||||||
FEC | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/10 8PSK: 3/5; 2/3; 3/4; 5/6; 8/9; 9/10 16APSK: 2/3; 3/4; 4/5; 5/6; 8/9; 9/10 32APSK: 3/4; 4/5; 5/6; 8/9; 9/10 | ||||||
Constellation | QPSK; 8PSK; 16APSK; 32APSK | ||||||
Max input bitrate | ≤170 Mbps | ||||||
DVB-S2X | Input Frequency | 950~2150MHz | |||||
Symbol rate | QPSK/8PSK /16APSK :0.5~45 Msps | ||||||
FEC | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/10; 13/45; 9/20; 11/20 | ||||||
Constellation | QPSK; 8PSK; 8APSK; 16APSK; 32APSK | ||||||
Max input bitrate | ≤170 Mbps | ||||||
| ATSC | ATSC | Input Frequency | 54-858MHz | |||
Bandwidth | 6 M | ||||||
Constellation | 8 VSB | ||||||
Descrambling | CAM/CI Quantity | 2 (per demodulation module) | |||||
BISS Mode | Mode 1; Mode E | ||||||
Output | 1*MPTS & 16*SPTS over UDP; RTP. | ||||||
1×ASI mirrored out of MPTS; BNC interface | |||||||
System | Remote management | Web-server Management | |||||
Language | English | ||||||
Upgrade | web management | ||||||
Miscellaneous | Dimension | 482*300*44mm (W×L×H) | |||||
Environment | 0~45℃(work);-20~80℃(Storage) | ||||||
Power requirements | 100~240VAC; 50/60Hz | ||||||
Power consumption | 15W | ||||||
Equipment guide:
When placing an order; please specify both the Demodulation module and Tuner Input options.
Each Demodulation Module = 2 or 4 *RF/Loop out + 2*CAM + 2*Smartcard
Demodulation Module | Option 1 | 1*Demodulation module; 2 CAM/CI Slots |
Option 2 | 2*Demodulation modules; 4 CAM/CI Slots |
Tuner Input (perdemodulation module) | Option 1 | 2*DVB-S/S2/S2X tuner |
Option 2 | 2*DVB-C/T/T2/ISDB-T tuner | |
Option 3 | 2*ATSC tuner | |
Option 4 | 4*DVB-S/S2/S2X tuner | |
Option 5 | 4*DVB-C/T/T2/ISDB-T tuner | |
Option 6 | 4*ATSC tuner | |
Option 7 | 2*DVB-S/S2/S2X tuner + 2*DVB-C/T/T2/ISDB-T tuner | |
Option 8 | 2*DVB-S/S2/S2X tuner + 2* ATSC tuner | |
Option 9 | 2*DVB-C/T/T2/ISDB-T tuner + 2*ATSC tuner |
