FMUSER DTV-4513E/F 2/4 ASI 1 IP(UDP) in DVB-S/S2 RF/IF Modulator
1.Support 4 ASI input ports and 1 IP
2.Constant temperature crystal oscillator, as high as 0.1ppm stability
3.External 10MHz reference clock input
4.Support BISS scrambling
5.Output frequency range: 50~960MHz
Details:
FMUSER DTV-4513E/F 2/4 ASI 1 IP(UDP) in DVB-S/S2 RF/IF Modulator
Overview:
FMUSER DTV-4513E is a high-performance modulator that has been developed in accordance with the DVB-S2 (EN302307) standard; which is the second-generation standard for European broadband satellite telecommunications. This modulator is designed to convert input satellite signals and/or ASI and IP streams into digital DVB-S/S2 RF output. It also includes BISS scrambling mode; which helps to ensure the safe distribution of your programs.
The DVB-S2 modulator is equipped with a web-server NMS software and an LCD in the front panel; making it easy to reach local and remote control. With its high cost-effective design; the FMUSER
DTV-4513E DVB-S2 modulator is widely used for broadcasting; interactive services; news gathering.
FMUSER DTV-4513F is a high-performance modulator developed in accordance with the DVB-S2 (EN302307) standard; which is the second-generation standard for European broadband satellite telecommunications. This modulator is designed to convert input ASI and IP signals alternatively into digital DVB-S2 IF output.
FMUSER DTV-4513E/F is a reliable and efficient solution for converting input ASI and IP signals into digital DVB-S/S2 RF/IF output. Its advanced features and ease of use make it an excellent choice for broadcasting and other broadband satellite applications.
Features:
FMUSER DTV-4513E:
The DTV-4513E is a modulator that fully complies with both DVB-S2 (EN302307) and DVB-S (EN300421) standards. It has ASI and/or DVB-S2 inputs for re-mux or pass through; with 4 ports for ASI and S2 tuner input combination.
It also supports IP (1000/100M) signal input for re-mux or pass through and multiplexing and PSI/SI edit.Supports QPSK; 8PSK; 16APSK; and 32APSK constellations; and has optional RF CID setting. It features a constant temperature crystal oscillator with up to 0.1ppm stability; and supports coupling 10Mhz clock output through the RF output port. It also supports 24V power output through the RF output port and BISS scrambling.
In addition; the modulator supports SFN TS transmission and has an output frequency range of 950~2150MHz with 10KHz stepping. It can be locally and remotely controlled with a Web-server NMS; making it easy to operate and manage. Overall; this modulator is an excellent choice for anyone looking for a reliable and flexible solution that complies with industry standards.
FMUSER DTV-4513F:
The FMUSER DTV-4513F is a modulator that fully complies with both DVB-S2 (EN302307) and DVB-S (EN300421) standards. It has 4 ASI inputs with 3 ASI inputs for backup. It also supports IP (100M) signal input.
The DTV-4513F features a constant temperature crystal oscillator with up to 0.1ppm stability and an external 10MHz reference clock input. It supports BISS scrambling and can be locally and remotely controlled.The output frequency range of the modulator is 50~960MHz; making it suitable for a variety of applications.
Overall; this modulator is a reliable and efficient solution for converting ASI and IP signals into digital output. Its advanced features and ease of use make it an excellent choice for broadcasting and other related applications.
Principle Chart:
FMUSER DTV-4513E
FMUSER DTV-4513F
Specification:
FMUSER DTV-4513E
IP Input | 1*IP Input (RJ45; 1000/100M TS Over UDP) | |||
ASI Input | Supporting both188/204 Byte Packet TS Input | |||
1-4 ASI Inputs (Connector: BNC; Impedance 75Ω) | ||||
Tuner Input |
DVB-S | Input Frequency | 950~2150MHz | |
Symbol rate | 0.5~45Msps | |||
Signal Strength | - 65- -25dBm | |||
FEC | 1/2; 2/3; 3/4; 5/6; 7/8 | |||
Constellation | QPSK | |||
Max input bitrate | ≤160 Mbps | |||
DVB-S2 | Input Frequency | 950~2150MHz | ||
Symbol rate | QPSK/8PSK /16APSK :0.5~45 Msps | |||
FEC | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/10 8PSK: 3/5; 2/3; 3/4; 5/6; 8/9; 9/10 | |||
Constellation | QPSK; 8PSK; 16APSK; 32APSK | |||
Max input bitrate | ≤160 Mbps | |||
DVB-S2X | Input Frequency | 950~2150MHz | ||
Symbol rate | QPSK/8PSK /16APSK :0.5~45 Msps | |||
FEC | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/10; 13/45; 9/20; 11/20 | |||
Constellation | QPSK/8PSK/8APSK/16APSK/32APSK | |||
Max input bitrate | ≤160 Mbps | |||
Multiplexing | Maximum PID |
128 input per channel | ||
Function | PID remapping (automatically or manually) | |||
Accurate PCR adjusting | ||||
Edit PSI/SI tables (PAT/PMT/SDT/CAT/NIT) | ||||
10MHz Reference Clock |
1*External 10MHz Input (BNC Interface); 1*Inner 10MHz Reference clock | |||
RF Output | RF Range: 950 ~ 2150 MHz; 10KHz stepping | |||
Output Level Attenuation:-26 ~ 0 dBm; 0.5dBm Stepping | ||||
MER≥40dB | ||||
Connector: N type; Impedance 50Ω; N to F adapter | ||||
FMUSER DTV-4513F
ASI Input | 4 ASI input ( 3 ASI for backup) | ||
Supporting 188Byte Transmission Stream Packet | |||
ASI Input Connector: BNC; Impedance 75Ω | |||
IP Input | 1*IP Input (Rj45; 100M TS Over UDP) | ||
10MHz Reference Clock | 1*External 10MHz Input (BNC Interface); 1*Inner 10MHz Reference Clock | ||
IF Output | Range: 50 ~ 960 MHz; 1KHz stepping | ||
Output Level Attenuation: 3dBm~28.5dBm; 0.5dBm Stepping | |||
MER≥40dB | |||
Connector: N type; impedance 50Ω | |||
Channel Coding and Modulation |
| DVB-S | DVB-S2 |
Outer coding | RS Coding | BCH Coding | |
Inner coding | Convolution | LDPC Coding | |
|
FEC/ |
1/2; 2/3; 3/4; 5/6; | QPSK: 1/2; 3/5; 2/3; 3/4; 4/5; 5/6; 8/9; 9/10 |
Constellation | QPSK | QPSK; 8PSK | |
Roll-off Factor |
0.2; 0.25; 0.35 |
0.2; 0.25; 0.35 | |
Symbol Rate | 0.05~45Msps | 0.05~45Msps | |
BISS |
Mode0; mode1; mode E | ||
System | Web-server NMS | ||
Language: English | |||
Ethernet software upgrade | |||
Miscellaneous | Dimension | 482mm×410mm×44mm | |
Temperature | 0~45℃(operation); -20~80℃ (storage) | ||
Power | 100-240VAC±10%; 50Hz-60Hz | ||
Equipment List:
| DTV-4513E | DTV-4513F | DTV-4514 | DTV-4514F |
DVB-S/S2 | ♦ | ♦ | ♦ | ♦ |
DVB- S2X |
|
| ♦ | ♦ |
QPSK; 8PSK | ♦ | ♦ | ♦ | ♦ |
16APSK; 32APSK | ♦ |
| ♦ | ♦ |
8APSK-L; 16APSK-L; 32APSK-L |
|
| ♦ | ♦ |
RF output (950-2150MHz) | ♦ |
| ♦ |
|
IF output ( 50 - 960MHz) |
| ♦ |
| ♦ |
